Aftermarket sound system

[99xcss4]

back on page 2 of this thread I did post links for both kicker and skar loaded enclosures as well as skar emty enclosures and I I posted some skar bass packages post 12 and 13 but here is kicker and skar full sub line-ups these do not come with enclosures like the ones on page 2 do https://www.kicker.com/car-subwoofers https://www.skaraudio.com/collections/car-subwoofers



[Feral peasant]

both kicker and skar have lose subs and loaded enclosures the 50.x4 is the speakers meaning your door and roof speakers would ad up to 200w and the smallest mono block that linked dose around 1000w so with 200 of the doors and 1000 for bass that is where the 1200 comes from and that is with the 70-80 efficiency

So what I have written down for the tweeters and speaker kit ranges from 15-125W RMS and the roof speakers 15-75W RMS are those ratings per speaker or in total if it was total then adding the max RMS together would be 250W for the door speakers and tweeter and 150W for the roof. 400W total max RMS granted I'll be running them off the head unit for now.
So the whole system minus the sub would run at 200W max off the head unit if I'm understanding this correctly

The SVR-2X12D4 RMS is 1,600W so would I need an amp rated for 1,600W RMS or would I run a little higher?



[Feral peasant]

back on page 2 of this thread I did post links for both kicker and skar loaded enclosures as well as skar emty enclosures and I I posted some skar bass packages post 12 and 13 but here is kicker and skar full sub line-ups these do not come with enclosures like the ones on page 2 do https://www.kicker.com/car-subwoofers https://www.skaraudio.com/collections/car-subwoofers

Yeah I was getting the enclosure ones, I don't know anyone to make them and I don't know how to myself.

Also if I get a dual sub I see the RMS is 1,200W is that per sub or in total?



[99xcss4]

So what I have written down for the tweeters and speaker kit ranges from 15-125W RMS and the roof speakers 15-75W RMS are those ratings per speaker or in total if it was total then adding the max RMS together would be 250W for the door speakers and tweeter and 150W for the roof. 400W total max RMS granted I'll be running them off the head unit for now.
So the whole system minus the sub would run at 200W max off the head unit if I'm understanding this correctly

The SVR-2X12D4 RMS is 1,600W so would I need an amp rated for 1,600W RMS or would I run a little higher?

ok for the door and roof speakers it dose not say if it is each or the pair maybe I missed it but the 15-125 and 15-75 is a guide you want to be between those figures per channel and imho the d4s mm504 would be a good way to go for that



[Feral peasant]

ok for the door and roof speakers it dose not say if it is each or the pair maybe I missed it but the 15-125 and 15-75 is a guide you want to be between those figures per channel and imho the d4s mm504 would be a good way to go for that

so in the future for the speakers I should get 1 of those MM504 the 300W amp

What about the sub? Because that will be the first thing wired to the amp I'm thinking I'll go with the SKAR. SDR-2X12D4



[99xcss4]

I do like the svr series looking at the the sub by it self it is ratted 800 rms per sub since you are looking at the dual loaded enclosure that means you double the 800 to 1600 out of the mono blocks that I recommended on page 5 the d4s jp12z3 is going to be the one but you are going to want that big 3 and second battery it not very efficient but it compact



[99xcss4]

so in the future for the speakers I should get 1 of those MM504 the 300W amp

What about the sub? Because that will be the first thing wired to the amp I'm thinking I'll go with the SKAR. SDR-2X12D4

if you are going to get a skar amp I would go with this it is a little on the high side but compaired to most of there amps it is very efficient https://www.skaraudio.com/products/sa-15001d-car-amplifier

xc_hide_links_from_guests_guests_error_hide_media



[Feral peasant]

I do like the svr series looking at the the sub by it self it is ratted 800 rms per sub since you are looking at the dual loaded enclosure that means you double the 800 to 1600 out of the mono blocks that I recommended on page 5 the d4s jp12z3 is going to be the one but you are going to want that big 3 and second battery it not very efficient but it compact

I plan to do the big 3 but a second battery might be a little much at this moment, but if I don't go with that SKAR amp I'll do this



[Feral peasant]

if you are going to get a skar amp I would go with this it is a little on the high side but compaired to most of there amps it is very efficient https://www.skaraudio.com/products/sa-15001d-car-amplifier

xc_hide_links_from_guests_guests_error_hide_media

You must be registered for see images attach



[Feral peasant]

looking over at ebay found some good amp install kit that are ofc and the right wire gauge

bass amp/mono block https://www.ebay.com/itm/385306095119?_skw=4+gauge+ofc+amp+kit&epid=26017600939&itmmeta=01JVDKR9GD3KZMEH67WDE1JN8Z&hash=item59b6086e0f:g:16sAAOSwcU5joogT&itmprp=enc:AQAKAAAA8FkggFvd1GGDu0w3yXCmi1eYN2yzNxJnugXrCY3XAme2ES/FuqnorQqS4Nopm0uXdWM7jJ727VpaV3sAgcv9sW7JEgDiS0YE7HUfMrtlaRgueCWzesCbyXOehk93sXJyJDp7jQH9rIrNzWpNsGKFT0Hu+ZwBEpzX8xzVzxSvX1yuI3R+lIwnaAfbGE6nk9s/Z2iq6/fX/QiOXozpEfVFUBOqXj8bsZOYuAZ4QFEkQP8tkV0Mlzc6pW5Z/jIDqUSbZlfdo9SbmhXeLeKu6X+xEJRj1/9FOgv82ku8k4vEBNnLPf5OCKCrfdL/1bYwISbGUA==|tkp:BFBMrpjhs9tl&keyword=4+gauge+ofc+amp+kit&sacat=0&relatedSearch=true 4 channel/mids and highs https://www.ebay.com/itm/390675795868?_trkparms=amclksrc=ITM&aid=777008&algo=PERSONAL.TOPIC&ao=1&asc=20230823115209&meid=9a2727b45ba2458c801ea5e5f3194b30&pid=101800&rk=1&rkt=1&itm=390675795868&pmt=0&noa=1&pg=4375194&algv=RecentlyViewedItemsV2SignedOut&brand=KnuKonceptz&_trksid=p4375194.c101800.m5481&_trkparms=parentrq:db3ba89a1960a47ffc5e4667ffffd71e|pageci:ddf35609-32a5-11f0-99d1-72890f952b01|iid:1|vlpname:vlp_homepage

You still recommend this to wire the sub amp?
